Lightmesh Tablet
Description
A mobile tablet with the Lightmesh app for managing complex lighting scenes and groups. It provides all-in-one control and monitoring for industrial, office, and school environments.
Body
Polycarbonate w/ G+FF anti-fingerprint glass
Attachments
-
- Height: 155 mm
- Width: 272 mm
- Depth: 13 mm
-
| Wattage | Height | Width | Depth | Product Code |
| N/A | 155 mm | 272 mm | 13 mm | SGL/LM/TAB |
-
• Operating Voltage - 100-240VAC,50/60Hz
• Operating Frequency - 2.4 GHz - 2.483 GHz
• Display - 10.1-inch IPS, resolution 1200×1920
• IP Rating - IP20
• Floorplan feature to simplify project planning
• Grouping luminaires via mesh network
• Scenes
• Compatible with Southgate Lighting switches
• Schedule to run scenes based on time and date
• Astro timer (sunrise and sunset)
• Device firmware update over-the-air
• Offline commissioning
• Different permission levels via authority management
• Network sharing via QR code or keycode
• Remote control via gateway support
• Interoperability with Southgate Bluetooth product portfolio
• Mains powered
• Designed for electrical box/junction box
• Keep real time for up to 7-8 weeks against power failure
• Manual adjustment: on/off, dim and color tuning
• Manual/Auto display screen brightness adjustment
• Touch screen with vibration/beeper/LED indication
• Clean mode/Screen lock time
• 5-year warranty
