Polaris LED

Description

The Polaris LED range is a high-specification, IP65-rated decorative luminaire designed to deliver exceptional performance. Its unique diffuser design ensures optimal light output without exposing the LEDs, while the edge diffuser creates an elegant decorative halo effect, enhancing the overall aesthetic appeal.

Body

Featuring a white polycarbonate body and a polycarbonate diffuser, this fixture provides both direct and edge lighting for a balanced illumination. It is IP65 rated for dust and moisture protection and TP(a) rated for fire safety, ensuring durability and reliability in demanding environments.

Application

  • Staircases
  • Corridors
  • Toilets
  • Social Areas

Attachments

  • Inbuilt PIR
  • Diameter: 360/430 mm
  • Depth: 110 mm

Tridonic/OSRAM

  • Standard LED
  • DALI Dimming LED
  • WI-FI
Wattage LuminousFlux lm/W Diameter Depth Product Code
15.2 W 2288 lm 150.5 lm/W 360 mm 110 mm SGL/LED/3/2740/POL
17.1 W 2572 lm 150.4 lm/W 360 mm 110 mm SGL/LED/3/3080/POL
19.2 W 2864 lm 149.2 lm/W 360 mm 110 mm SGL/LED/3/3430/POL

20.3 W 3156 lm 155.5 lm/W 430 mm 110 mm SGL/LED/4/3780/POL
22.4 W 3465 lm 154.7 lm/W 430 mm 110 mm SGL/LED/4/4150/POL
24.6 W 3783 lm 153.8 lm/W 430 mm 110 mm SGL/LED/4/4530/POL

Outputs above are based on 4000k colour temperature. Additional lumen outputs are available due to mA ratings and codes may vary from those stated. Please contact us for further details.

  • Add /EMG to codes for Emergency Mode
  • Add /EMG/ST to codes for Self-test Emergency
  • Add /EMG/AD to codes for Addressable Emergency
  • Add /DALI to codes for DALI Dimming
  • Add /PIR to codes for Inbuilt PIR
  • Module efficacy up to 191 lm/W
  • >72,000h L90 at 25°C
  • MacAdam Step 3
  • Self Cooling
  • Colour Rendering Index >80
  • 7 Year Guarantee*
  • CE/UKCA Marked

* Please refer to the Warranty for more information.

** Subject to change.

  • Tridonic/OSRAM LED
  • Colour Temperatures Availabe: 3000/4000/5000 k
  • All LED data and performance data is taken at an ambient temperature of +25°C
