Pisces LED
Recessed Luminaires
Description
The Pisces LED is expertly designed for clean rooms and sterile environments, suitable for both suspended and solid ceilings. Featuring a vandal-resistant micro-prism diffuser, it provides robust mechanical protection while softly diffusing LED light to meet IP65 standards. Side arm suspensions are included as standard, ensuring secure and reliable installation.
Body
Constructed from 1mm bright steel with a durable white electrostatic powder-coated finish, this fixture combines strength and style. The frame, made from 1.5mm (16 SWG) steel, enhances rigidity for added durability. Designed to IP65 standards for protection against dust and moisture, it also features TP(a) rated diffusers as standard, ensuring safety and compliance in demanding environments. Plasterboard and surface mounting kits are available to accommodate a variety of ceiling types, ensuring versatile installation options.
Application
- Kitchen Areas
- Care Homes
- Industrial Areas
Attachments
- Inbuilt PIR
Other sizes may be manufactured as specials. |
 |
Tridonic/OSRAM
- Standard LED
- DALI Dimming LED
- WI-FI
| Wattage | Luminous Flux | lm/W | Length | Width | Depth | Product Code |
| 18.5 W | 2916 lm | 157.6 lm/W | 625 mm | 625 mm | 90 mm | SGL/LED/6x6/3480/PIS |
| 21.8 W | 3402 lm | 156.1 lm/W | 625 mm | 625 mm | 90 mm | SGL/LED/6x6/4060/PIS |
| 25.0 W | 3888 lm | 155.5 lm/W | 625 mm | 625 mm | 90 mm | SGL/LED/6x6/4640/PIS |
| 28.4 W | 4375 lm | 154.0 lm/W | 625 mm | 625 mm | 90 mm | SGL/LED/6x6/5220/PIS |
| 31.7 W | 4781 lm | 153.3 lm/W | 625 mm | 625 mm | 90 mm | SGL/LED/6x6/5800/PIS |
| 18.5 W | 2868 lm | 155.0 lm/W | 1225 mm | 325 mm | 90 mm | SGL/LED/12x3/3480/PIS |
| 21.8 W | 3347 lm | 153.5 lm/W | 1225 mm | 325 mm | 90 mm | SGL/LED/12x3/4060/PIS |
| 25.0 W | 3825 lm | 153.0 lm/W | 1225 mm | 325 mm | 90 mm | SGL/LED/12x3/4640/PIS |
| 28.4 W | 4303 lm | 151.5 lm/W | 1225 mm | 325 mm | 90 mm | SGL/LED/12x3/5220/PIS |
| 31.7 W | 4781 lm | 150.8 lm/W | 1225 mm | 325 mm | 90 mm | SGL/LED/12x3/5800/PIS |
| 37.1W | 5819 lm | 156.8 lm/W | 1225 mm | 625 mm | 90 mm | SGL/LED/12x6/6960/PIS |
| 46.6 W | 6788 lm | 145.7 lm/W | 1225 mm | 625 mm | 90 mm | SGL/LED/12x6/8120/PIS |
| 50.1 W | 7758 lm | 154.9 lm/W | 1225 mm | 625 mm | 90 mm | SGL/LED/12x6/9280/PIS |
| 56.8 W | 8728 lm | 153.7 lm/W | 1225 mm | 625 mm | 90 mm | SGL/LED/12x6/10440/PIS |
| 63.5 W | 9698 lm | 152.7 lm/W | 1225 mm | 625 mm | 90 mm | SGL/LED/12x6/11600/PIS |
Additional lumen outputs are available due to mA ratings and codes may vary from those stated. Please contact us for further details.
- Add /EMG to codes for Emergency
- Add /EMG/ST to codes for Self-Test Emergency
- Add /EMG/AD to codes for Addressable Emergency
- Add /DALI to codes for DALI Dimming
- Add /PIR to codes for Inbuilt PIR
- Module efficacy up to 184 lm/W
- 50,000h L90 at 25°C
- Self Cooling
- Colour Rendering Index >80
- 7 Year Guarantee*
- CE Marked
- Tridonic/OSRAM LED
- Colour Temperatures Available: 3000k/4000k/5000k
- All LED data and performance data is taken at an ambient temperature of +25°C
