Vista LED

Description

The Vista LED is a square bollard with a built in light source. This light fitting is designed for outdoor areas with an IP65/IK10 rating.

Extruded aluminium, or stainless steel, housing with flush mounting base, vandal-resistant screws and a powder-coated. IP65/IK10 rated.

Tridonic/OSRAM

Wattage	Luminous Flux	lm/W	Height	Width	Depth	Product Code
7.4 W	949 lm	128.2 lm/W	400 mm	100 mm	100 mm	SGL/LED/04/1200/VIS
7.4 W	949 lm	128.2 lm/W	600 mm	100 mm	100 mm	SGL/LED/06/1200/VIS
7.4 W	949 lm	128.2 lm/W	1000 mm	100 mm	100 mm	SGL/LED/1/1200/VIS
7.4 W	949 lm	128.2 lm/W	1200 mm	100 mm	100 mm	SGL/LED/12/1200/VIS

Additional lumen outputs are available due to mA ratings and codes may vary from those stated. Please contact us for further details.

Module efficacy up to 128.2 lm/W
50,000h L90/F10 at 25°C - F value is derived by combining B (number of units under L threshold) and C (number of fatal unit failures). F value demonstrates a far more realistic value of life expectancy.**
Self Cooling
Colour Rendering Index >80
7 Year Guarantee*
CE Marked

* Please refer to the Warranty for more information.

** Subject to change.
