Hayley LED
Downlight Luminaires
Description
For spaces requiring contemporary but efficient downlighting with a touch of elegance, our Hayley LED range provides outstanding performance combined with a decorative design. This versatile range also offers various colour and attachment options to suit diverse settings and styles.
Body
Crafted from die-cast aluminium and featuring a high-performance heat sink, this design ensures both durability and efficient lumen output for long-lasting performance. The optional etched glass ring, paired with spacers, creates a striking floating effect, enhancing its visual appeal. The twist-and-lock bezel provides easy access for maintenance, combining both style and practicality. With an IP54 rating, it offers reliable protection against dust and moisture, making it ideal for various indoor applications.
Application
- Offices
- Circulation Areas
- Toilets
- Double Height Areas
- Architectural Areas
Attachments
- Inbuilt PIR
- Any Bezel Colour Available (White Bezel as Standard)
- Brushed Aluminium Bezel
- Saturn Black Reflector
- Floating Glass Ring (Various Colours Available)
|
 |
Tridonic/OSRAM
- Standard LED
- DALI Dimming LED
- DMX Colour Changing LED
- Wireless Bluetooth
| Wattage | Luminous Flux | lm/W | Diameter | Depth | Product Code |
| 7.1 W | 1071 lm | 150.8 lm/W | 195mm | 115mm | SGL/LED/1210/HAY/IP54 |
| 10.7 W | 1602 lm | 149.7 lm/W | 195mm | 115mm | SGL/LED/1810/HAY/IP54 |
| 14.4 W | 2133 lm | 148.0 lm/W | 195mm | 115mm | SGL/LED/2410/HAY/IP54 |
| 18.1 W | 2673 lm | 147.7 lm/W | 195mm | 115mm | SGL/LED/3020/HAY/IP54 |
| 21.8 W | 3204 lm | 147.0 lm/W | 195mm | 115mm | SGL/LED/3620/HAY/IP54 |
| 25.7 W | 3735 lm | 145.3 lm/W | 195mm | 115mm | SGL/LED/4220/HAY/IP54 |
Outputs above are based on 4000k colour temperature. Additional lumen outputs are available due to mA ratings and codes may vary from those stated. Please contact us for further details.
- Add /EMG to codes for Emergency
- Add /EMG/ST to codes for Self-Test Emergency
- Add /EMG/AD to codes for Addressable Emergency
- Add /DALI to codes for DALI Dimming
- Add /RGB to codes for Colour Changing
- Add /PIR to codes for PIR Control
- Add /WH to codes for White Bezel
- Add /CH to codes for Chrome Bezel
- Add /BA to codes for Brushed Aluminium Bezel
- Add /SBR to codes for Saturn Matt Reflector
- Add /DO to codes for Domed Opal Diffuser
- Add /FGR to codes for Floating Glass Ring
- Add /GR to codes for Glass Ring
- Trimless Plastered-In (No Bezel)
- Module efficacy up to 193 lm/W
- 60,000h L90 at 25°C
- MacAdam Step 3
- Self Cooling
- Colour Rendering Index >80
- 7 Year Guarantee*
- CE/UKCA Marked
* Please refer to the Warranty for more information.
** Subject to change.
- Tridonic/OSRAM LED
- Colour Temperatures Available: 3000k/4000k/5000k/RGB
- All LED data and performance data is taken at an ambient temperature of +25ºC
