Alcatraz LED

Anti-Ligature Luminaires

Description

The Alcatraz LED provides a sleek, durable solution for environments requiring IK-rated and anti-ligature fittings. With an IP54 rating, it effectively prevents dust and insects from entering the fixture, ensuring long-lasting performance. The end caps are securely fastened with stainless steel anti-tamper screws, making the fitting tamper-proof and ideal for high-security applications. IP65 version available.

Body

Crafted from 1.0mm CR4 steel and finished with a high-gloss electrostatic powder coating, this fixture combines strength with a sleek aesthetic. It features a high-output prismatic opal TP(a) diffuser, ensuring optimal light diffusion and compliance with UGR<19 for visual comfort. With IK12 impact resistance and an IP54 rating, it offers reliable protection against dust, moisture, and physical damage, making it ideal for demanding environments. IP65 version available.

Application

Health Care Buildings
Prisons
Industrial Maintenance Areas
Pit/Underground Areas

Attachments

Inbuilt PIR
Night-Light
IP65 Version

Sizes

Length: 580/1190/1470 mm
Width: 150 mm
Depth: 100 mm

Control Gear

Tridonic/OSRAM

Standard LED
DALI Dimming LED
Wireless Bluetooth

Catalogue Codes

Wattage	Luminous Flux	lm/W	Length	Width	Depth	Product Code
11.5 W	1677 lm	145.8 lm/W	580 mm	150 mm	100 mm	SGL/LED/06/2260/ALC
16.3 W	2345 lm	143.9 lm/W	580 mm	150 mm	100 mm	SGL/LED/06/3160/ALC
21.1 W	3013 lm	142.8 lm/W	580 mm	150 mm	100 mm	SGL/LED/06/4060/ALC

23.2 W	3354 lm	144.6 lm/W	1190 mm	150 mm	100 mm	SGL/LED/12/4520/ALC
32.7 W	4689 lm	143.4 lm/W	1190 mm	150 mm	100 mm	SGL/LED/12/6320/ALC
42.5 W	6025 lm	141.8 lm/W	1190 mm	150 mm	100 mm	SGL/LED/12/8120/ALC

28.9 W	4185 lm	144.8 lm/W	1470 mm	150 mm	100 mm	SGL/LED/15/5640/ALC
40.8 W	5862 lm	143.7 lm/W	1470 mm	150 mm	100 mm	SGL/LED/15/7900/ALC
52.9 W	7524 lm	142.2 lm/W	1470 mm	150 mm	100 mm	SGL/LED/15/10140/ALC

Additional lumen outputs are available due to mA ratings and codes may vary from those stated. Please contact us for further details.

Code Options

Add /EMG to codes for Emergency
Add /EMG/ST to codes for Self-Test Emergency
Add /EMG/AD to codes for Addressable Emergency
Add /DALI to codes for DALI Dimming
Add /WI-FI to codes for Wireless Bluetooth
Add /IP65 to codes for IP65 Version

Main Attributes

Module efficacy up to 213 lm/W
50,000h L90/F10 at 25°C - F value is derived by combining B (number of units under L threshold) and C (number of fatal unit failures). F value demonstrates a far more realistic value of life expectancy.**
Self Cooling
Colour Rendering Index >80
7 Year Guarantee*
CE Marked

* Please refer to the Warranty for more information.

** Subject to change.
